Microscopio profesional trinocular AmScope SM-1TZ lentes WH10x ampliación de 35X-90X zoom objetivo de 07X-45X iluminación ambiental estilo de pilar

Descripción
The AmScope SM-1TZ professional trinocular stereo zoom microscope has a pair of 10x super-widefield high-eyepoint eyepieces, a 0.7x-4.5x zoom objective, two Barlow lenses, and a pillar stand. The microscope has an overall magnification range of 3.5x-90x. The trinocular viewing head has an interpupillary range of 55 to 75mm, a 45-degree inclination to reduce eye and neck strain, and 360-degree rotation to enable sharing. The vertical trinocular port can be used as a C-Mount or 23mm photo port (camera sold separately). The WH10x20mm super-widefield high-eyepoint eyepieces combine with the 0.7x-4.5x zoom objective to provide zoom magnification and a longer working distance for inspecting large-scale specimens that require handling or repair. The microscope comes with 0.5x and 2.0x Barlow lenses that can be added to the objective to increase the magnification range. A Barlow lens with a magnification of less than 1.0 reduces magnification and increases the working distance, while a Barlow lens with a magnification greater than 1.0 increases the magnification and reduces the working distance. High-eyepoint eyepieces ease viewing for users who wear glasses, and dioptric adjustment accommodates individual eye-strength differences. A stereo microscope, sometimes called an inspection or dissection microscope, has low magnification and a long working distance that enables users to manipulate the object being inspected. Ambient lighting illuminates the specimen, eliminating the need for power or batteries. The pillar-style stand secures the head for precise focusing. Bilateral coarse focus eases use for left- and right-handed users. The extra-large table stand has a reversible black and white stage plate that provides contrast with light and dark-colored specimens, and stage clips to secure the specimen in place. The stage plate has a 3-3/4″ diameter (95mm). The stage is 3/4 x 10 x 12-1/2 inches/20 x 280 x 320mm (H x W x D, where H is height, the vertical distance from the lowest to highest point; W is width, the horizontal distance from left to right; D is depth, the horizontal distance from front to back).SpecificationsHeadTrinocularMagnification range3.5x-90xZoom objective power0.7x-4.5xEyepieces (DIN, 30mm)WH10x20mm high-eyepointTrinocular portC-Mount or 23mmField of view range2-1/2″Optical working distanceUp to 8″Microscope standPillar-style table standHead movementX-axisIllumination typeN/ALight sourceAmbientPowerN/AMicroscopes are instruments used to enhance the resolution of an object or image. Types include compound, stereo, or digital. Compound microscopes use a compound optical system with an objective lens and an eyepiece. Stereo microscopes show object depth in a three-dimensional image. Digital microscopes are used to display an image on a monitor, rather than looking through a lens. Microscopes can have monocular (one), binocular (two), or trinocular (three) eyepieces, with varying magnification abilities. Magnification ability refers to the size of an image. Resolution, also known as resolvant power, refers to the clarity of the image. The interaction between field of view (FOV), numerical aperture (NA), and working distance (WD) determines resolution. Microscopes can control magnification through a fixed focus, or through a range of adjustments. They can also utilize LED, fluorescent, and mirror light sources to help control viewing capabilities. Microscopes are widely used in education, lab research, biology, metallurgy, engineering, chemistry, manufacturing, and in the medical, forensic science, and veterinary industries.United Scope manufactures microscopy equipment and accessories under the brand name AmScope. The company, founded in 1996, is headquartered in Irvine, CA.What’s in the Box?AmScope SM-1TZ stereo zoom microscope with pillar standWH10x20mm eyepieces, 30mm, one pair0.7x-4.5x zoom objective0.5x Barlow lens2.0x Barlow lensFocus rackEye guards, one pairStage clips, one pairDust cover
Características
Microscopio estéreo profesional con soporte pilar tiene larga distancia de trabajo para permitir a los usuarios realizar trabajos o manipular artículos de gran tamaño, incluyendo tableros de circuito y aparatos dentales Trinocular cabeza con 2 unidades de visualización de 10 x oculares super-widefield fija, ajustable distancia interpupilar, de 45 grados inclinación vertical para reducir la tensión en cuello y ojos, y la capacidad de rotación de 360 grados para permitir a compartir Zoom 0,7 x -4,5 X lente proporciona ampliación de zoom continuo y más longitud focal para inspeccionar especímenes de gran escala, un 0,5 x Barlow lente se extiende la distancia de trabajo, y una lente Barlow 2.0 x extiende el rango de ampliación Iluminación ambiental ilumina el espécimen, eliminando la necesidad de poder o pilas extragrande de soporte de mesa reversible con blanco y negro placa etapa proporciona contraste con la decoloración y dark-colored especímenes, y la fase clips asegurar la specimen durante visualización
El número de Modelo (ItemModelNumber)
SM-1TZ
Peso
3.25 Libras
Dimensiones
19.6 x 16.4 x 16 pulgadas
Fabricante es United Scope LLC.
Destacados
Microscopio estéreo profesional con soporte pilar tiene larga distancia de trabajo para permitir a los usuarios realizar trabajos o manipular artículos de gran tamaño, incluyendo tableros de circuito y aparatos dentales, Trinocular cabeza con 2 unidades de visualización de 10 x oculares super-widefield fija, ajustable distancia interpupilar, de 45 grados inclinación vertical para reducir la tensión en cuello y ojos, y la capacidad de rotación de 360 grados para permitir a compartir, Zoom 0,7 x -4,5 X lente proporciona ampliación de zoom continuo y más longitud focal para inspeccionar especímenes de gran escala, un 0,5 x Barlow lente se extiende la distancia de trabajo, y una lente Barlow 2.0 x extiende el rango de ampliación, Iluminación ambiental ilumina el espécimen, eliminando la necesidad de poder o pilas, extragrande de soporte de mesa reversible con blanco y negro placa etapa proporciona contraste con la decoloración y dark-colored especímenes, y la fase clips asegurar la specimen durante visualización
La calificación que le dan a Microscopio profesional trinocular AmScope SM-1TZ lentes WH10x ampliación de 35X-90X zoom objetivo de 07X-45X iluminación ambiental estilo de pilar grande soporte para mesa incluye lentes 05X y 20X Barlow, 29 usuarios es de 3.9 sobre 5 estrellas.
El País de Origen (COO, siglas en inglés) o fabricación del producto Microscopio profesional trinocular AmScope SM-1TZ lentes WH10x ampliación de 35X-90X zoom objetivo de 07X-45X iluminación ambiental estilo de pilar grande soporte para mesa incluye lentes 05X y 20X Barlow es China.
