Siemens QSA2020SPD Protección contra sobretensiones para toda la casa con dos disyuntores de 20 amperios para uso solo en paneles Siemens

Descripción
Reseña del editor Siemens El dispositivo SPD proporciona protección contra sobretensiones en toda la casa. Este dispositivo ocupa el espacio de dos interruptores estándar de un solo polo, pero también incluye dos interruptores de un solo polo para que no pierda espacio en su centro de carga. Una vez conectado en el panel, el dispositivo SPD protege todo el panel y todos los circuitos de derivación de sobretensiones, no solo los dos circuitos conectados al SPD. El nivel de sujeción inicial es de 240 voltios. Los LED proporcionan notificación de estado de protección. Siemens recomienda encarecidamente contra el uso de interruptores «usados». La instalación de interruptores usados en un panel Siemens anulará la garantía en el panel. Siemens no vende interruptores usados y no ha aprobado ningún vendedor de terceros para hacerlo. Tienda In today’s electronic world, your home’s electrical, phone and cable systems are incomplete unless they incorporate surge protection. Since most everything in the home is microelectronic based, it is not practical to solely rely on surge protected plug strips. By installing this Siemens circuit breaker and surge protective device (SPD) in the load center of your home, surge protection is provided for all branch circuits. This version (model QSA2020SPD) is rated at 20 amps, and it’s also available in a 15 amp version.The 20 amp QSA2020SPD surge protection device (view larger). The QSA2020SPD features a highly effective TVSS integrated with two 1-pole circuit breakers and incorporates the robust features of a secondary circuit breaker surge arrester with a lower clamping voltage ratings. Once connected in the panel, the SPD device protects the entire panel and all branch circuits from surges, not just the two circuits connected to the SPD. Two green LEDs provide protection status notification, and the device will notify you of any loss of surge protection by tripping one or both of the circuit breakers. These breakers should be used for circuit protection of frequently used household or facility circuits as the lights and devices connected to these circuits provide an effective indication that surge protection is being provided. All Type QP circuit breakers and SPD are plug-on style, with load terminals provided. The devices are rated for 120/240V AC and are calibrated for 40 degrees C maximum ambient applications.Surge Protective DevicesTo effectively surge protect your appliances and other sensitive electronic equipment, you need to stop surges before they get into your home and also control surges generated inside your home. Damaging surges enter your home primarily through the main utility power source, coax and telephone services. When left unprotected, surges will permeate throughout the home damaging electronics and appliances.What is a surge?A surge, sometimes called a transient or a spike, is a brief burst of energy (voltage and current). The most damaging surges enter through your home’s power, cable and telephone lines. However, the majority of surges originate within the home from the action of motor based appliances like dishwashers, refrigerators, garage door openers, etc.How do surges affect my equipment?Large surges can damage equipment by «burning up» the internal components of your sensitive electronic equipment and appliances. Moderate surges disrupt equipment operation and damage internal components. Lower energy surges degrade equipment, which is referred to in the industry as «electronic rust.»Why do you need this type of surge protection?The only way to surge protect microelectronic based appliances is through the application of an incoming service entrance surge protector like a Siemens SPD.QSA2020SPD Specifications Amperage 20 amps Number of Poles Two 1-pole circuit breakers Initial Clamping Level 240 volts Transient Energy Rating 360 Joules line-to-neutral 720 Joules line-to-line Transient Suppression 500 volts peak, line-to-neutral Voltage Rating 1000 volts peak, line-to-line Peak Current Rating (impulse) 40,000 amperes Discharge Voltage Characteristic @ 1,500A, 600 volts @ 5,000A, 800 volts (both line-to-neutral) Discharge Current Withstand Rating 10,000 amperes (line-to-neutral) Circuit Breaker Interrupting Rating 10,000A, 120/240V AC Listings/Certifications UL, CSA; meets UL 1449 3rd Edition QSA2020SPD Whole House Surge ProtectionAt a GlanceTwo 20 amp circuit breakersProvides whole house surge protectionTakes up the space of two standard single pole breakers, but also includes two single pole breakersInitial clamping level is 240 voltsHandy LED lights provide protection status notification Protect your home from electrical surges.
Características
Proporciona protección contra sobretensiones en toda la casa Ocupa el espacio de dos disyuntores estándar de un solo polo, pero también incluye dos disyuntores de un solo polo.Varistores de óxido metálico de 150 VAC, 1.575 in El dispositivo SPD protege todo el panel y todos los circuitos de derivación de sobretensiones El nivel de sujeción inicial es de 240 voltios Prácticas luces LED que proporcionan notificación de estado de protección
El número de Modelo (ItemModelNumber)
‎US2:QSA2020SPD
Peso
10.00 Pounds
Dimensiones
3 x 2 x 3 pulgadas
Fabricante es ‎Siemens
Destacados
Proporciona protección contra sobretensiones en toda la casa, Ocupa el espacio de dos disyuntores estándar de un solo polo, pero también incluye dos disyuntores de un solo polo.Varistores de óxido metálico de 150 VAC, 1.575 in, El dispositivo SPD protege todo el panel y todos los circuitos de derivación de sobretensiones, El nivel de sujeción inicial es de 240 voltios, Prácticas luces LED que proporcionan notificación de estado de protección
La calificación que le dan a Siemens QSA2020SPD Protección contra sobretensiones para toda la casa con dos disyuntores de 20 amperios para uso solo en paneles Siemens, 665 usuarios es de 4.5 sobre 5 estrellas.
El País de Origen (COO, siglas en inglés) o fabricación del producto Siemens QSA2020SPD Protección contra sobretensiones para toda la casa con dos disyuntores de 20 amperios para uso solo en paneles Siemens es ‎China.
