Descripción
Victor 0781-5219 ETS4-200-540 Professional Two Stage ETS4 EDGE Series High Capacity Regulator features user friendly architecture with a side mounted knob that makes it easier to adjust with a more natural and safer hand/body position for adjusting delivery pressure. Gauges are easy to read with high contrast graphics. The advanced design is smaller and lighter than our previous models, the edge design is the perfect blend of form and functionality. The durable construction is designed with a single impact point configured to help protect elements critical to system integrity. Compact layout includes gauges that are built in and recessed into the body for protection. Outstanding flow performance provides better flow control across a full range of cylinder pressures, with exceptional sensitivity in delivery pressure control. This regulator meets or exceeds industry standards, including he stringent ASTM G-175 promoted ignition test. Color-coded knobs make it is easy for operator to glance to identify gas type whether indoors, outdoors or far away. Shock limitation and absorption (SLAM) technology is built into the adjusting knob helps protect regulator vitals and reduces the chance of injury in the event of a cylinder accident. Delivery range is 10-200 PSIG. Gauge range inlet is 4000 and the outlet is 400. CGA inlet connection is 540 and the outlet connection is 9/16 inch – 18 M RH. Maximum inlet pressure is 3000 PSIG. Flow coefficient is 0.488 Cv.
Características
Alcance de entrega es de 10 – 200 psig Medidor Rango de entrada es 4000 y la salida es de 400 CGA conexión de entrada es de 540 y la conexión de salida es de 9/16 inch – 18 M derecha) Máxima presión de entrada es 3000 psig Coeficiente de flujo es 0,488 CV
El número de Modelo (ItemModelNumber)
0781-5219
Peso
0.01 Onzas
Dimensiones
7 x 8 x 8 pulgadas
Fabricante es Victor
Destacados
Alcance de entrega es de 10 – 200 psig, Medidor Rango de entrada es 4000 y la salida es de 400, CGA conexión de entrada es de 540 y la conexión de salida es de 9/16 inch – 18 M derecha), Máxima presión de entrada es 3000 psig, Coeficiente de flujo es 0,488 CV
