35MM Concealed Hinge Jig, Hinge Drilling Tool Set，Suitable for Face Frame Cabinet Cupboard Door Hinges, DIY Tools for Cabinet Door Installation

Lo más importante

Power Tool Parts & Accessories de la marca SPARIK ENJOY

• Marca: SPARIK ENJOY
• Categoría: Power Tool Parts & Accessories
• Calificación: 4,0/5
• Valoraciones: 83

Datos técnicos destacados

• Calificación promedio de 4,0/5.
• 83 valoraciones visibles.

Preguntas resueltas

Products Specifications: Material:Plastic,Metal Main Component Size: 225x95x25mm/8.9"x3.7"x1"(L*W*H) Bracket Height:36mm/1.4" Bracket Diameter:58mm/2.3" Bracket Hole Diameter:13mm/0.5" Positioning Rod Length:40mm/1.6" Drill Length:49mm/1.9" Limit Ring Diameter:11mm/0.4" Wrench Size:102x22mm/4"x0.9" (L*W) The hinged puncher is suitable for 35mm and 26mm hinge,and supports the mounting screw hole 46-47-48-52 temporarily. It is easy to use and install,if you are not professional,also you can handle it easily. Instructions: 1.Put the hole cutter through the bracket and fix it with the limit ring. 2.Put the step 1 to the principal part,then turn it clockwise to fix it. 3.the black block is for adjusting limit,adjust distance from 35mm hole to board ,you can choose 3/4/5/6mm. 4.Drilling the hole, then can install the hinge. Please Notes: All dimensions are measured manually and there may be small deviations. Keep hands and body clear of sharp edges and moving parts. Always wear eye protection. Clamp guide in place during use. Package Content: 1 x Yellow Principal Part 1 x Limit Ring 2 x Auxiliary accessories 1 x Bracket 1 x Positioning Rod 1 x Drill 1 x Wrench 1 x 35mm/1.4" Hole Cutter (Put in the blue box)
